ANLASSER AUDI, SEAT, VW 1.9TDI 03- BX
'
ANLASSER AUDI, SEAT, VW 1.9TDI 03- BX
HP/570267 | Hersteller: BOSCH | Herstellernummer: 0 986 020 250
Produkteigenschaften
174,44 EUR ohne Mwst.
207,58 EUR inkl. Mwst.
Technische Eigenschaften
| Eigenschaft | Wert |
|---|---|
| EAN | 316514352656 |
| Starterleistung [kW] | 1,7 |
| Anzahl der Befestigungsbohrungen | 3 |
| Anzahl der Gewindebohrungen | 0 |
| Zähnezahl |
|
| Klemme |
|
| Flanschdurchmesser [mm] | 76,2 |
| Drehrichtung | Drehrichtung gegen den Uhrzeigersinn |
| Ritzel-Grundposition [mm] | 52,5 |
| Starterausführung | freiausstoßend |
| Bohrungsdurchmesser [mm] | 12,5 |
| Bohrungsdurchmesser 2 [mm] | 12,5 |
| Bohrung-Ø 3 [mm] | 12,5 |
| Länge [mm] | 246 |
| Lage/Grad | links |
| Befestigungswinkel [Grad] | 44 |
| Winkelmaß Befestigungsbohrung [Grad] | 44 |
| Spannung [V] | 12 |
Kompatible Fahrzeuge
| Modell | kW | CCM | PS | Baujahr |
|---|---|---|---|---|
| AUDI A3 (8P1) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/05-2010/05 |
| AUDI A3 Sportback (8PA) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/09-2010/05 |
| AUDI A3 Cabriolet (8P7) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2008/04-2009/10 |
| Modell | kW | CCM | PS | Baujahr |
|---|---|---|---|---|
| SEAT IBIZA III (6L1) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2002/02-2009/11 |
| SEAT IBIZA III (6L1) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2002/05-2005/12 |
| SEAT IBIZA III (6L1) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/06-2009/11 |
| SEAT CORDOBA (6L2) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2002/09-2009/11 |
| SEAT CORDOBA (6L2) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2002/10-2005/12 |
| SEAT CORDOBA (6L2) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/06-2009/11 |
| SEAT ALTEA (5P1) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/04-2010/12 |
| SEAT ALTEA (5P1) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2009/08-2010/12 |
| SEAT TOLEDO III (5P2) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/10-2009/05 |
| SEAT LEON (1P1) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2005/07-2010/12 |
| SEAT LEON (1P1) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2007/06-2010/12 |
| SEAT ALTEA XL (5P5, 5P8) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2006/10-2010/12 |
| SEAT ALTEA XL (5P5, 5P8) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2009/08-2010/12 |
| SEAT ALTEA XL (5P5, 5P8) 1.9 TDI 4x4 | 77 KW | 1896 CCM | 105 KM | 2009/06-2010/12 |
| SEAT IBIZA IV (6J5, 6P1) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2008/07-2010/06 |
| SEAT IBIZA IV (6J5, 6P1) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2008/07-2010/06 |
| SEAT IBIZA IV (6J5, 6P1) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2008/03-2010/06 |
| SEAT IBIZA IV SC (6J1, 6P5) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2008/07-2010/06 |
| SEAT IBIZA IV SC (6J1, 6P5) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2008/06-2010/06 |
| SEAT IBIZA IV SC (6J1, 6P5) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2008/07-2010/06 |
| Modell | kW | CCM | PS | Baujahr |
|---|---|---|---|---|
| SKODA FABIA I (6Y2) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2000/01-2008/03 |
| SKODA FABIA I (6Y2) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2003/04-2008/03 |
| SKODA FABIA I (6Y2) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/10-2008/03 |
| SKODA FABIA I Combi (6Y5) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2000/04-2007/12 |
| SKODA FABIA I Combi (6Y5) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2003/04-2007/12 |
| SKODA FABIA I Combi (6Y5) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/10-2007/12 |
| SKODA FABIA I Stufenheck (6Y3) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2000/01-2007/12 |
| SKODA FABIA I Stufenheck (6Y3) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2003/04-2007/12 |
| SKODA FABIA I Stufenheck (6Y3) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/10-2007/12 |
| SKODA FABIA I Praktik (6Y5) 1.9 TDI | 74 KW | 1896 CCM | 101 KM | 2000/01-2007/12 |
| SKODA FABIA I Praktik (6Y5) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2004/08-2005/10 |
| SKODA OCTAVIA II (1Z3) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/06-2010/12 |
| SKODA OCTAVIA II Combi (1Z5) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/09-2010/12 |
| SKODA ROOMSTER (5J7) 1.9 TDI | 74 KW | 1896 CCM | 101 KM | 2006/03-2006/05 |
| SKODA ROOMSTER (5J7) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2006/09-2010/03 |
| SKODA ROOMSTER (5J7) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2006/09-2010/03 |
| SKODA FABIA II (542) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2007/01-2010/03 |
| SKODA FABIA II (542) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2007/04-2010/03 |
| SKODA FABIA II Combi (545) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2007/10-2010/03 |
| SKODA FABIA II Combi (545) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2007/10-2010/03 |
| SKODA ROOMSTER Praktik (5J) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2007/03-2010/03 |
| SKODA SUPERB II (3T4) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2008/03-2010/11 |
| SKODA SUPERB II Kombi (3T5) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2009/10-2010/11 |
| Modell | kW | CCM | PS | Baujahr |
|---|---|---|---|---|
| VW POLO IV (9N_, 9A_) 1.9 TDI | 74 KW | 1896 CCM | 101 KM | 2001/10-2009/11 |
| VW POLO IV (9N_, 9A_) 1.4 TDI | 59 KW | 1422 CCM | 80 KM | 2005/04-2009/11 |
| VW POLO IV (9N_, 9A_) 1.4 TDI | 51 KW | 1422 CCM | 70 KM | 2005/04-2009/11 |
| VW TOURAN (1T1, 1T2) 1.9 TDI | 74 KW | 1896 CCM | 100 KM | 2003/02-2004/05 |
| VW TOURAN (1T1, 1T2) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/08-2010/05 |
| VW TOURAN (1T1, 1T2) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2004/11-2010/05 |
| VW MULTIVAN T5 (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/04-2009/11 |
| VW MULTIVAN T5 (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI | 75 KW | 1896 CCM | 102 KM | 2006/01-2009/11 |
| VW MULTIVAN T5 (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI | 63 KW | 1896 CCM | 85 KM | 2003/04-2009/11 |
| VW MULTIVAN T5 (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI | 62 KW | 1896 CCM | 84 KM | 2006/01-2009/11 |
| VW GOLF V (1K1) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/10-2008/11 |
| VW GOLF V (1K1) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2004/05-2008/11 |
| VW GOLF V (1K1) 1.9 TDI 4motion | 77 KW | 1896 CCM | 105 KM | 2004/08-2008/11 |
| VW TRANSPORTER T5 Pritsche/Fahrgestell (7JD, 7JE, 7JL, 7JY, 7JZ 1.9 TDI | 63 KW | 1896 CCM | 85 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Pritsche/Fahrgestell (7JD, 7JE, 7JL, 7JY, 7JZ 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Pritsche/Fahrgestell (7JD, 7JE, 7JL, 7JY, 7JZ 1.9 TDI | 75 KW | 1896 CCM | 102 KM | 2006/01-2009/11 |
| VW TRANSPORTER T5 Pritsche/Fahrgestell (7JD, 7JE, 7JL, 7JY, 7JZ 1.9 TDI | 62 KW | 1896 CCM | 84 KM | 2006/01-2009/11 |
| VW TRANSPORTER T5 Kasten (7HA, 7HH, 7EA, 7EH) 1.9 TDI | 63 KW | 1896 CCM | 85 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Kasten (7HA, 7HH, 7EA, 7EH) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Kasten (7HA, 7HH, 7EA, 7EH) 1.9 TDI | 75 KW | 1896 CCM | 102 KM | 2006/01-2009/11 |
| VW TRANSPORTER T5 Kasten (7HA, 7HH, 7EA, 7EH) 1.9 TDI | 62 KW | 1896 CCM | 84 KM | 2006/01-2009/11 |
| VW TRANSPORTER T5 Bus (7HB, 7HJ, 7EB, 7EJ) 1.9 TDI | 63 KW | 1896 CCM | 85 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Bus (7HB, 7HJ, 7EB, 7EJ) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/04-2009/11 |
| VW TRANSPORTER T5 Bus (7HB, 7HJ, 7EB, 7EJ) 1.9 TDI | 75 KW | 1896 CCM | 102 KM | 2006/01-2009/11 |
| VW TRANSPORTER T5 Bus (7HB, 7HJ, 7EB, 7EJ) 1.9 TDI | 62 KW | 1896 CCM | 84 KM | 2006/01-2009/11 |
| VW POLO IV Stufenheck (9A4, 9A2, 9N2, 9A6) 1.4 TDI | 55 KW | 1422 CCM | 75 KM | 2003/07-2005/06 |
| VW CADDY III Kasten/Großraumlimousine (2KA, 2KH, 2CA, 2CH) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/04-2010/08 |
| VW CADDY III Kasten/Großraumlimousine (2KA, 2KH, 2CA, 2CH) 1.9 TDI | 55 KW | 1896 CCM | 75 KM | 2005/09-2010/08 |
| VW CADDY III Großraumlimousine (2KB, 2KJ, 2CB, 2CJ) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2004/04-2010/08 |
| VW CADDY III Großraumlimousine (2KB, 2KJ, 2CB, 2CJ) 1.9 TDI | 55 KW | 1896 CCM | 75 KM | 2005/09-2010/08 |
| VW GOLF PLUS V (5M1, 521) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2005/01-2009/01 |
| VW GOLF PLUS V (5M1, 521) 1.9 TDI | 66 KW | 1896 CCM | 90 KM | 2005/05-2008/12 |
| VW PASSAT B6 (3C2) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2005/03-2010/07 |
| VW JETTA III (1K2) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2005/08-2010/10 |
| VW PASSAT B6 Variant (3C5) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2005/08-2010/11 |
| VW GOLF V Variant (1K5) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2007/06-2009/07 |
| VW GOLF V Variant (1K5) 1.9 TDI 4motion | 77 KW | 1896 CCM | 105 KM | 2008/01-2009/07 |
| VW POLO IV Stufenheck (9N2, 9N4) 1.9 TDI | 74 KW | 1896 CCM | 101 KM | 2003/07-2010/12 |
| VW TOURAN VAN (1T1, 1T2) 1.9 TDI | 74 KW | 1896 CCM | 101 KM | 2003/10-2005/05 |
| VW TOURAN VAN (1T1, 1T2) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2003/08-2006/11 |
| VW CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) 1.9 TDI | 63 KW | 1896 CCM | 85 KM | 2007/05-2009/11 |
| VW CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) 1.9 TDI | 77 KW | 1896 CCM | 105 KM | 2007/05-2009/11 |
| VW CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) 1.9 TDI | 75 KW | 1896 CCM | 102 KM | 2007/05-2009/11 |
| VW CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) 1.9 TDI | 62 KW | 1896 CCM | 84 KM | 2007/05-2009/12 |
Herstellernummern
Stück
Ersatz
| Teilenummer | Bezeichnung | Teile-Code | Hersteller | Einkauf | Verkauf | H | Verfügbarkeit |
|---|---|---|---|---|---|---|---|
| HP/513665 | ANLASSER AUDI,SEAT,VW 1.9TDI 03- | S0090 | AS-PL | 52,64 | 52,64 | Verfügbare Ware in Ihrer Filiale - 1 Stück für Morgen - >10 Stück für Übermorgen - 2 Stück | |
| HP/530786 | Anlasser AUDI,SEAT,VW 1 9TDI 03- | 530 786 | HART | 41,19 | 41,19 | 0,6993 | für Morgen - 2 Stück |
| Teilenummer | Bezeichnung | Teile-Code | Hersteller | Einkauf | Verkauf | H | Verfügbarkeit |
|---|---|---|---|---|---|---|---|
| HP/570231 | Anlasser Audi A3 1.9 03- | 1 986 S00 797 | BOSCH | 76,76 | 76,76 | für Morgen - 2 Stück |
